Chenbro SR10569-C4+ CS SR10569 1x120mm Fan PWM 1xFan 80mm Retail

The Chenbro SR10569-C4+ CS SR10569 1x120mm Fan PWM 1xFan 80mm Retail is a high-quality computer chassis designed to support various components and provide efficient cooling. With its removable 4-bay 3.5" HDD hot-swap and internal cages, this chassis offers ample storage options and easy accessibility. It supports up to 12" x 13" M/B form factor, making it compatible with a wide range of motherboards.

Features & Benefits

• Supports up to 12" x 13" M/B
• Supports removable 4-bay 3.5" HDD hot-swap and internal cages
• 3.5" HDD hot-swap cages with 12Gb/s Mini-SAS HD or SAS/SATA backplane
• Hot-swap cage with four patented tool-less 3.5" HDD trays
• 3.5" internal HDD cage with patented anti-vibration technologies
• A dedicated 80mm fan for 3.5" HDD cooling
• An optional 80mm front fan for PCI-e card cooling
• Supports PCI-e 3.0 expansion slot opening
• Tool-less installation for bezel, HDD cage, side cover, and fans
• Supports key lock, 3-wire intrusion switch, and Kensington security slot
• Front bezel lock to prevent unauthorized access
• Supports rack installation by slide rails (SR10566 Plus only)
• Supports single PS/2 and 1+1 Redundant PSU

Specifications

• M/B Form Factor: SSI EEB (12" x 13")
• Drive Bays:
  • External 5.25": 3
  • 3.5" Hot-swap: 4
  • 3.5" Internal (Option): 4
• PSU Form Factor: PS/2 Single or N+1 Redundant
• Indicators:
  • 1 x Power Status
  • 2 x LAN Activity
  • 1 x HDD Status
  • 1 x System Alarm
• Front Buttons:
  • 1 x Power On/Off
  • 1 x System Reset
  • 1 x Alarm Mute
  • 2 x USB2.0/USB3.0 (Option)
• System Security:
  • Intrusion Switch
  • Key Lock
  • Kensington Slot
• Cooling Fans:
  • HDD Cage: 80 x 25 (1)
  • PCI: 80 x 25 (1) (Option)
  • Rear: 120 x 25 (1)
• Expansion Slots: 7 x Full Height (5 x Full Length + 2 x Half Length)
• HDD Backplane:
  • 3.5" 4-port 12Gbps, Mini-SAS HD
  • 3.5" 4-port 12Gbps, SAS/SATA (Option)
• Metal Thickness: 0.8mm
• Front Bezel: Option
• Weight: 27.00 lb
• Warranty Information: 3 Years

Learn More

For more information about this product, please visit the Computer Chassis Wikipedia page.

For detailed specifications and technical information, refer to the Chenbro Wikipedia page.

Product: Chenbro SR10569-C4+ Cs Sr10569 1X120Mm Fan Pwm 1Xfan 80Mm Retail

Brand: Chenbro

Model: SR10569-C4+

Shipping Weight: 27.00 lb

Shipping Height: 0.00 in

Shipping Width: 0.00 in

Shipping Length: 0.00 in
