StarTech 10P6G-PCIE-SATA-CARD PCIe x4 SATA III Controller

This 10-port SATA III (6Gbps) controller enables you to add 10 SATA 6Gbps Hard Drives (HDDs) or Solid State Drives (SSDs) to your computer system or server via an available PCIe x4 card slot. The card supports SATA III and PCI-Express 2.0 Specifications.

Features:

• Operating relative humidity (H-H): 20 - 80
• Storage temperature (T-T): -25 - 85
• Operating temperature (T-T): 0 - 85
• Data transfer rate (max): 6
• Port multiplier: Y
• Master (outer) case length: 380
• Quantity per master (outer) case: 60
• Host interface: PCIe
• Package depth: 170
• Package height: 30
• Package width: 142
• Master (outer) case height: 310
• Master (outer) case width: 500
• Quick installation guide: Y
• S.M.A.R.T. support: Y
• Internal: Y
• Weight: 75
• Chipset: ASMedia - ASM1062
• Package weight: 120
• Height: 16
• Width: 54
• Depth: 139
• Product color: Red
• Windows operating systems supported: Windows 7 Ultimate x64,Windows 10,Windows 7 x64,Windows 10 Education,Windows 8,Windows 10 Education x64,Windows 7,Windows 8 Enterprise,Windows 10 Enterprise,Windows 7 Enterprise,Windows 8 Enterprise x64,Windows 10 Enterprise x64,Windows 7 Enterprise x64,W
• Mac operating systems supported: Mac OS X 10.13 High Sierra,Mac OS X 11.0 Big Sur,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 10.10 Yosemite,Mac OS X 10.15.3 Catalina,Mac OS X 10.11 El Capitan
• Linux operating systems supported: Y
• Server operating systems supported: Windows Server 2019,Windows Server 2012 R2,Windows Server 2016
• TRIM support: Y
• Output interface: SATA
• Internal SATA ports quantity: 10
• Expansion card standard: PCIe 2.0
• Sustainability certificates: CE,RoHS
• Mounting brackets included: Y

Learn More

For more information, visit PCI Express on Wikipedia

For more information, visit Serial ATA on Wikipedia

Product: StarTech 10P6G-PCIE-SATA-CARD PCIe x4 SATA III Controller

Brand: Startech.Com

Model: 10P6G-PCIE-SATA-CARD

Shipping Weight: 0.30 lb

Shipping Height: 1.30 in

Shipping Width: 5.60 in

Shipping Length: 6.80 in
