StarTech.com ST1000SPEXD4 StarTech Network Dual Port Gigabit PCI-Express Server

The StarTech.com ST1000SPEXD4 PCI Express Dual-Port Gigabit Network Card is a high-performance networking card that allows you to add two gigabit Ethernet ports to a client, server, or workstation through a single PCIe slot. With each port providing 10/100/1000 Mbps capable Ethernet and full compatibility with IEEE 802.3/u/ab standards, this network card ensures reliable and fast network connectivity.

Designed for standard PCI Express-enabled systems, this 2-port Ethernet card supports full-duplex flow control, allowing for maximum data transfer speeds of up to 2000 Mbps. This makes it an ideal choice for setting up dual-homed or multi-homed host configurations, providing added security to corporate networks.

The ST1000SPEXD4 is compliant with the PCIe 2.0 standard and features support for advanced networking features such as Jumbo Frames and 802.1q VLAN tagging. It also includes Wake on LAN (WoL) support, enabling remote wake-up functionality. The adapter comes with an optional low-profile/half-height bracket, making it suitable for installation in standard or small form-factor computer chassis.

The StarTech.com Advantage:

• Protect critical networked systems with a redundant and independent Gigabit port
• Optimize network traffic with support for advanced features such as Jumbo Frames and VLAN tagging
• Maximize the networking efficiency of your virtualized server with dedicated ports

Product Features

• Connectivity technology: Wired
• Host interface: PCI Express
• Interface: Ethernet
• Internal: Yes
• Ethernet LAN (RJ-45) ports: 2
• Maximum data transfer rate: 2000 Mbps
• Full duplex: Yes
• Chipset: Realtek - RTL8111E, Asmedia - ASM1182E
• Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
• Jumbo frames support: Yes
• Auto MDIX IEEE: Yes
• Windows operating systems supported: Windows 10 Education, Windows 10 Enterprise, Windows 10 Home, Windows 10 IOT Core, Windows 10 Pro, Windows 2000, Windows 7, and more
• Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, and more
• Linux operating systems supported: Yes
• Width: 18 mm
• Depth: 92.6 mm
• Height: 120 mm
• Weight: 51 g
• Package weight: 142 g
• RoHS compliance: Yes
• Operating temperature (T-T): 0 - 70 &degC
• Storage temperature (T-T): 0 - 100 &degC
• Operating relative humidity (H-H): 10 - 90%

Product: StarTech.com ST1000SPEXD4 StarTech Network Dual Port Gigabit PCI-Express Server

Brand: Startech.Com

Model: ST1000SPEXD4

Shipping Weight: lb

Shipping Height: in

Shipping Width: in

Shipping Length: in
