Supermicro SSG-5049P-E1CTR36L 4U LGA3647 C622 36x3.5HS SATA SAS Server

The Supermicro SuperStorage Server 5049P-E1CTR36L is a powerful server designed for CPU Intensive Storage, Virtual Storage, Single Instance Storage and Data Deduplication, Data Replication, Business Continuity, and Virtual Tape Library customer environments. This server supports node based deployment strategies where CPU and HDD capacity scale together, or deployments can be expanded using JBODs for improved economy. It features low-latency SSD applications, large media files requiring massive capacity, and enterprise workloads looking for the highest performance. The SAS 3.0 (12Gbps) support provides low-latency and maximum data bandwidth for demanding applications.

With a Socket P (LGA 3647) and Intel C622 chipset, this server supports up to 1TB 3DS ECC LRDIMM or 256GB ECC RDIMM memory. It offers PCI-E 3.0 slots, NVMe support, flexible networking options such as 10G SFP+, 10GBase-T LAN ports, and IPMI 2.0 with KVM and dedicated LAN. The Supermicro SuperStorage Server 5049P-E1CTR36L is compatible with the latest Intel Xeon Scalable processors, providing high performance and reliability for your storage needs.

Features:

• Processor socket: LGA 3647
• Motherboard chipset: Intel C622
• Built-in processor: N
• Number of processors supported: 1
• Number of DIMM slots: 8
• Maximum internal memory: 1000
• Maximum RDIMM memory: 192
• Chassis type: Rack (4U)
• Product color: Black
• LED indicators: HDD, Heating, Network, Power, Power fail
• Width: 437 mm
• Depth: 699 mm
• Height: 178 mm
• Weight: 29700 g
• Package weight: 46400 g
• RoHS compliance: Yes
• On/off switch: Yes
• Number of fans: 7
• Fan diameter: 80 mm
• Operating temperature (T-T): 10 - 35 &degC
• Storage temperature (T-T): -40 - 60 &degC
• Operating relative humidity (H-H): 8 - 90%
• Storage relative humidity (H-H): 5 - 95%
• Number of redundant power supplies installed: 2
• Power supply: 1200 W
• Redundant power supply (RPS) support: Yes
• Backplanes support: Yes
• Supported memory types: DDR4-SDRAM
• Supported RDIMM clock speeds: 2133, 2400, 2666
• RAID levels: 0, 1, 5, 10
• Hot-swap hard drive bays: Yes
• Storage drive sizes supported: 3.5"
• Number of 3.5" bays: 12
• Supported storage drive interfaces: M.2, Serial Attached SCSI (SAS)-3, Serial ATA III
• LAN controller: Intel X557, Intel X722
• Copper ethernet cabling technology: 10GBASE-T
• Ethernet LAN: Yes
• USB 2.0 ports quantity: 2
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
• VGA (D-Sub) ports quantity: 1
• Ethernet LAN (RJ-45) ports: 2
• IPMI LAN (RJ-45) port: Yes
• Serial ports quantity: 1
• PCI Express x16 slots: 1
• PCI Express x8 slots: 2
• PCI Express x4 slots: 1
• PCI Express slots version: 2.0, 3.0
• On-board graphics adapter model: Aspeed AST2500
• BIOS type: UEFI AMI
• PC health monitoring: CPU, FAN, Temperature
• Compatible processor series: Intel Xeon

Learn More

• Supermicro on Wikipedia

Product: Supermicro SSG-5049P-E1CTR36L 4U LGA3647 C622 36x3.5HS SATA SAS Server

Brand: Supermicro

Model: SSG-5049P-E1CTR36L

Shipping Weight: 140.00 lb

Shipping Height: 18.00 in

Shipping Width: 27.00 in

Shipping Length: 40.00 in
