Victron Energy BP-65 BatteryProtect 65A 6-35VDC - BPR000065400

The Victron Energy BP-65 BatteryProtect is a high-quality battery protection device designed to safeguard your battery from damage caused by excessive discharge or insufficient power for engine cranking. With a current rating of 65A and a voltage range of 6-35VDC, this BatteryProtect offers reliable protection for your battery system.

Features:

• The BatteryProtect disconnects the battery from non-essential loads to prevent complete discharge or insufficient power for engine cranking.
• 12/24V auto ranging: The BatteryProtect automatically detects the system voltage for easy installation.
• Programming made easy: Set the BatteryProtect to engage/disengage at different voltage levels using the seven-segment display.
• Special setting for Li-ion batteries: Control the BatteryProtect using the VE.Bus BMS, making it suitable for use with Li-ion batteries.
• Ultra-low current consumption: Ideal for Li-ion batteries, especially after low voltage shutdown.
• Over-voltage protection: Disconnects the load when the DC voltage exceeds 16V or 32V to prevent damage to sensitive loads.
• Ignition proof: MOSFET switches eliminate sparks, ensuring safety.
• Delayed alarm output: Activates the alarm if the battery voltage drops below the preset disconnect level for more than 12 seconds.
• Delayed load disconnect and reconnect: The load is disconnected 90 seconds after the alarm activation, and reconnected 30 seconds after the battery voltage increases above the preset reconnect voltage.

Specifications:

• Current Rating: 65A
• Voltage Range: 6-35VDC

Learn More:

• Battery
• Lithium-ion Battery
• MOSFET

Product: Victron Energy Bpr000065400 Batteryprotect Bp-65 65Amp 6-35 Vdc

Brand: Victron Energy

Model: BPR000065400

Shipping Weight: 0.50 lb

Shipping Height: 3.00 in

Shipping Width: 3.00 in

Shipping Length: 6.00 in
